Liv

LIV AVAIL ADVANCED 3 (5TH GEN)

$3,000.00
New
3 payments of $1,000.00 with
Color: Ice Age
Size: XS
Doorstep Delivery

Local Delivery: Estimated 1-2 business days.
Third-party Couriers: Estimated 2-5 business days.
Color: Ice Age
Size: XS

Highlight

The Avail Advanced is that riding buddy who’s up for any adventure on the road—from solo backroad explorations to after-work shop rides to all-day epic rides with friends. Designed for performance and capable on any surface, this road warrior is ready to take you as far as you can go, which is always farther than you think.

KEY PERFORMANCE FACTORS

Lightweight Advantage

The Avail Advanced delivers lightweight efficiency, thanks to an all-new Advanced-grade composite frame and an Advanced-grade composite fork, which boosts your climbing abilities and makes you virtually uncatchable over long distances.

Superior Compliance

Ride longer without riding harder, with the re-engineered frame and fork, optimised for the smoothest, most efficient riding experience. The innovative Liv Contact D-Fuse handlebar and D-Fuse seatpost absorb more road vibrations than round-shaped tubing, without sacrificing efficiency on corners and climbs.

Maximum Control

The Liv Contact D-Fuse handlebar features an ergonomic shape and 8-degree flare drop, for total control on those sunrise-to-sunset rides. Wide, alloy rims are designed for high-volume tubeless tyres (up to 40mm), providing predictable handling and stability from asphalt to pavé.

SPECIFICATIONS
  • Sizes
    XXS, XS, S, M, L
  • Colors
    Ice Age
  • Frame
    Advanced-Grade Composite, 12x142mm thru-axle, disc
  • Fork
    Advanced-Grade Composite, full-composite OverDrive steerer, 12x100mm, disc
  • Shock
    N/A
  • Handlebar
    Liv Contact SL D-Fuse, 31.8mm XXS:38cm, XS:38cm, S:40cm, M:40cm, L:42cm
  • Grips
    Liv All Condition
  • Stem
    Giant Contact XXS:70mm, XS:70mm, S:80mm, M:90mm, L:90mm
  • Seatpost
    Giant D-Fuse, composite, -5/+15mm offset XXS:350mm, XS:350mm, S:350mm, M:350mm, L:350mm
  • Saddle
    Liv Approach
  • Pedals
    N/A
  • Shifters
    Shimano Tiagra, ST-R4720
  • Front Derailleur
    Shimano Tiagra, FD-4700
  • Rear Derailleur
    Shimano Tiagra, RD-4700
  • Brakes
    Shimano Tiagra hydraulic, BR-R4770, Giant MPH rotor [F]160mm, [R]160mm
  • Brake Levers
    Shimano 105 Di2, ST-4720
  • Cassette
    Shimano Tiagra, 10-speed, 11x34, CS-R4700
  • Chain
    KMC X10
  • Crankset
    Shimano Tiagra, 34/50T, FC-R4700
    XXS:165mm, XS:165mm, S:170mm, M:170mm, L:172.5mm
  • Bottom Bracket
    Shimano, press fit
  • Rims
    Giant S-R2 Disc wheelset
  • Hubs
    Giant S-R2 Disc wheelset, 12mm thru-axle
  • Spokes
    Giant S-R2 Disc wheelset
  • Tires
    Giant Gavia Fondo 1, tubeless, 700x32c (33.5mm), folding
  • Extras
    tubeless prepared, 40mm max tire size

*All specifications and prices listed are subject to change without notice.

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary by country.


Avail Advanced (5th Gen)


XXS XS S M
A SEAT TUBE LENGTH (mm) 385 405 435 465
B SEAT TUBE ANGLE 75.0° 74.5° 74.5° 74.0°
C TOP TUBE LENGTH (mm) 500 520 525 535
D HEAD TUBE LENGTH (mm) 110 125 145 165
E HEAD TUBE ANGLE 69.8° 71.0° 71.0° 71.0°
F FORK RAKE (mm) 50 50 50 50
G TRAIL (mm) 76 68 68 68
H WHEELBASE (mm) 989 995 1002 1007
I CHAIN STAY LENGTH (mm) 420 420 420 420
J BOTTOM BRACKET DROP (mm) 75 75 73 73
K STACK (mm) 510 528 547 566
K STACK TO HANDLEBAR (mm) 588 606 626 647
L REACH (mm) 363 373 373 373
L REACH TO HANDLEBAR (mm) 408 420 429 439
M STAND OVER HEIGHT (mm) 683 712 737 762
N HANDLEBAR WIDTH (mm) 380 380 400 400
O STEM LENGTH (mm) 70 70 80 90
P CRANK LENGTH (mm) 165 165 170 170
Q WHEEL SIZE 700C 700C 700C 700C

*All measurements shown are in millimetres unless otherwise stated.
