DESCRIPTION
The Max 50 WheelSystem delivers refined race-day performance through an ultralight, super-stiff aero system. At 1290g, its Max integrated hub,Super Aero carbon spokes and Dynamic Balanced Lacing optimize efficiency and power transfer for sharp acceleration and confident control.
FEATURES
- 50mm Aero Rim Profile – A deep 50mm rim profile maximizes aerodynamic efficiency, reducing drag for sustained high-speed performance in race conditions.
- Integrated Max Hub And Spoke Technology – A one-piece hub, flange, spoke, and rim structure forms a fully integrated system that minimizes drag, smooths airflow, and maximizes real-world efficiency at speed.
- Precision Reinforced Carbon Layup – High-tensile fibres are strategically placed only where needed to create a strong, torsionally stiff structure while minimizing overall weight.
- CADEX Super Aero Carbon Spokes – High-tensile integrated carbon spokes with hidden nipples and independent internal tensioning minimize lateral flex for efficient acceleration and responsive climbing.
- Dynamic Balanced Lacing (DBL) – A wider bracing angle and balanced spoke tension under pedaling load result in a stiffer wheel with outstanding power transfer and handling precision.
- 22.4mm Inner Width – A wide 22.4mm internal rim creates a more efficient tyre profile with an increased contact patch, improving sidewall support and confident handling at speed.
- CADEX R3-C48 Aero Hub – An aerodynamic hub design with a 48-tooth ratchet delivers fast, direct engagement for immediate power transfer during accelerations and surges.
- Ratchet Wave Spring System – A wave spring design ensures consistent, balanced ratchet engagement, resulting in smoother operation and improved rolling efficiency.
- CADEX Hookless Rim Technology – An optimized carbon layup and hookless rim design reduce weight while improving durability and tyre stability under high-speed loads.
- In-Mould Carbon Graphics – CADEX logos are integrated directly into the carbon surface for a clean, premium finish with no decals, no added weight, and no risk of fading.
SPECIFICATIONS
| Rim Material | Carbon |
|---|---|
| Rim Type | Hookless (Tubeless), rim tape and valves included |
| Rim Height | 50mm |
| Rim Outer Width | 30mm |
| Rim Inner Width | 22.4mm |
| Front Hub | CADEX R3 Centerlock One-piece integrated hub and spokes |
| Rear Hub | CADEX R3-C48, Ratchet Driver, Centerlock One-piece integrated hub and spokes |
| Freehub Compatibility | Shimano / SRAM XDR / Campagnolo N3W |
| Bearing | CADEX Ceramic Bearings |
| Front Axle | 100x12 TA (not included) |
| Rear Axle | 142x12 TA (not included) |
| Spokes | Super Aero Carbon Spoke, one-piece hub flange and spoke design |
| Nipple Type | Hidden Integrated Titanium Nipple |
| Warranty | Lifetime warranty |
| Incident Replacement | 5 year (registered original owner only) |
| Weight (Pair) | ~1,290 (including valves and rim tape) |
| WheelSystem Weight Limit | 285 lbs / 129 kg |
Â
*Please note that the Continental GP5000 S TR tyre is apt for use on CADEX hookless WheelSystems and is a different tire from the previous generation Continental GP5000 TL tyre. Please also note that as per Continental's specifications on rim inner width, the Continental GP5000 S TR in size 700x25C is apt for use only on the CADEX 42 and CADEX 42 Disc WheelSystems.
**Minimum tyre size for the following wheelsets are 28mm (700x28c and larger, or 700x25c for Giant/Cadex tyres. Info for reference.Â
- Cadex 36
- Cadex 40 Max
- Cadex 50 Ultra
- Cadex 65
- Cadex 4-Spoke / Cadex 4-Spoke 1K
- Cadex Aero Disc / Max Aero Disc
***Please note that only the Pirelli Cinturato Velo tire with a maximum pressure of 72psi (5 bar) indicated on the tire sidewall is apt for use with CADEX hookless WheelSystems.
